Sound Engine

100% Analog

Polyphony

Selectable monophonic or paraphonic

Keybed

37-note, semi-weighted with after-pressure

LCD

128 X 64-pixel LCD with white backlight

Controllers

Pitch Bend, Mod Wheel, After Pressure, Velocity

Sound Source

2 x variable waveshape oscillators

1 x square wave sub oscillator

1 x analog noise generator

1 x external input/filter feedback

Oscillator

Oscillator Calibration Range: 22 Hz to 6.8 kHz, (Note range at 8' = 18 to 116)

Portamento

Glide Module: Assign to Osc1/Osc2/Both, (Type - LCR, LCT, EXP, Gated, Legato)

Filter

20 Hz to 20 kHz Moog Ladder Filter with 6/12/18/24 dB/oct filter slopes and multidrive

Transpose

±2 octaves

Arpeggiator

Arpeggiator / Sequencer: Up, Down, Order, Random, Latching, Back/Forth, Invert, +/-2 Range, Tie, Rest, MIDI Sync, 64-note sequencer

Inputs and Outputs

Audio Input: 1 x 1/4" / 6.35 mm TS

Audio Output: 1 x 1/4" / 6.35 mm TS

Headphone Output: 1 x 1/4" / 6.35 mm TRS with separate volume control

Presets

256 Presets: 16 banks x 16 presets

MIDI I/O

MIDI In: 5-pin DIN connector

MIDI Out: 5-pin DIN connector

MIDI over USB: USB Type-B

CV In/Out Controls

CV/Gate Inputs: Filter CV, Pitch CV, Volume CV, KB Gate

Source

Sources: LFO (Triangle, Square, Saw, Ramp, Sample & Hold), Filter EG/PGM

Programmable Sources: Amp Env, Constant ON, Sine LFO, Noise LFO, Osc 1 Pitch, Osc 2 Pitch, Seq Note, Seq Vel, and Seq Mod

Destinations

Destinations: Osc 1 Pitch, Osc 2, Osc 1 & 2 Pitch, Filter, LFO Rate, VCA Level, Osc 1 Wave, Osc 2 Wave, Osc 1 & 2 Wave, Noise Level, EG Time/PGM

Programmable Destinations: Filter Resonance, Filter Drive, Filter Slope, Filter Env Amount, Filter Keyboard Amount, Osc 1 Level, Sub Osc Level, Osc 2 Level, External In/Feedback Level, Osc 1 On, Sub Osc On, Osc 2 On, Noise On, External In/Feedback On, Arp Rate, Arp Clock Division, Arp Range, Arp Back/Forth, Arp Ends, Arp Invert, Arp Gate Length, Arp Run, Glide Time, Glide OSC Choice, Glide Type, Glide Gate, Glide Legato, Glide On, LFO 1 Clock Division, LFO 1 Range, LFO 1 Sync, LFO 1 Keyboard Reset, LFO 1 Keyboard Track, Mod 1 Pitch Amount, Mod 1 Filter Amount, Mod 1 Programmable Amount, Mod 1 Programmable Destination, LFO 2 Clock Division, LFO 2 Range, LFO 2 Sync, LFO 2 Keyboard Reset, LFO 2 Keyboard Track, Mod 2 Pitch Amount, Mod 2 Filter Amount, Mod 2 Programmable Amount, Mod 2 Programmable Destination, Osc 1 Oct, Osc 2 Sync, Osc 2 Keyboard Reset, Osc 2 Oct, Osc 2 Keyboard Control, Osc 2 DUO Mode, Osc 2 Freq, Osc 2 Beat Freq, Filter Env Attack, Filter Env Decay, Filter Env Sus, Filter Env Release, Filter Env Delay, Filter Env Hold, Filter Env Vel Amount, Filter Keyboard Track, Filter Env Multitriggering, Filter Env Reset, Filter Env Sync, Filter Env Loop, Filter Env Latch, Amp Env Attack, Amp Env Decay, Amp Env Sus, Amp Env Release, Amp Env Delay, Amp Env Hold, Amp Env Vel Amount, Amp Keyboard Track, Amp Env Multitriggering, Amp Env Reset, Amp Env Sync, Amp Env Loop, Amp Env Latch, Output Volume, Bend Up, and Bend Down.

LFO

LFO Panel Features: Hi/Low range from .01 Hz to 1 kHz, MIDI Sync, KB Reset

Envelopes

DAHDSR Envelopes with Multi-Trigger, Reset, Looping, MIDI Sync, Latch, and Variable control of EG Delay, Hold, Velocity Amount, KB Tracking
